Atr 3 Slot
Available in 1/2, 3/4, 1 and 1 1/2 ATR tall long or tall short formats per ARINC 404A, ARINC 600 and IEEE 1101.10 specifi cations, the modular design concept allows for a wide range of customization options without the cost and lead time penalties associated with custom designs. 3 SLOT. 5 SLOT. 6 SLOT. 7 SLOT. 9 SLOT. cPCI-SERIAL MILITARY COTS ATR CHASSIS CM Military Chassis PSU Options The Leading military ATR & VME I/O manufacturer in Europe and the USA CM provides customization support for customers who wish to develop systems that are not available from our cataloged line of COTS.
Description
- 1ATR ARINC 404A Tall/Long format or 1ATR ARINC 404A Short/Long
- Rugged: Meets the requirements for shock, vibration and structural integrity per MIL-STD-810
- Power in: Single or three phase 90-264VAC or 28VDC power
- Cooling: Air flows around a finned, conduction cooled internal, sealed chassis and exits rear of chassis pulled by a single exhaust Tubeaxial high air flow 28V exhaust fan (can be powered with internal AC supplies) – less expensive option desired
- Eight 6U VITA 48.2 (REDI) )0 inch pitch conduction cooled payload slots in Long format (# of slots in Short format TBD)
- Configurable rigid front I/O PCBA and 7.5” x 7.5” front panel with Hercules® high-speed, ruggedized, circular mil connectors allows customization to exact application requirements
- Three tri-color front panel LED’s to indicate power supply status, temperature, and fan fail indicator
- Optional front panel hour meter (offered at additional cost – less expensive option desired). Dawn power supplies have integrated Power On Hours Meter than can be read over I2C or USB
- Guarded front panel integrated breaker power switch
- Front panel plug-in 7mm hard drive bay (internal mounting option)
- Optional dust filters (offered at additional cost)
- Front-mounted carrying handles
- ATR tray locks
- 50 ms at 500 W Mountable Holdup module available as an option.
Power Supply Features
- Includes one or two field replaceable Dawn VME Intelligent 3U VITA 62 AC or DC wedgelock conduction cooled power supplies (i.e., the wedgelock supplies are located such that they are also cooled through the bulkhead)
- Future model to offer one replaceable Dawn VME Intelligent 6U 1600W VITA 62 DC wedgelock conduction cooled power supply (i.e., the wedgelock supply is located such that they are also cooled through the bulkhead)
Atr 3 Slot Poker
Ordering Information
Order P/N ATR-TBD
Introduction
The Aitech E104 cold plate conduction-cooled VME computer enclosure is built to be rugged and reliable as well as lightweight and compact. EMI/RFI protected and environmentally sealed, the E104 is capable of withstanding extreme environmental conditions of high altitude, temperature, humidity, shock, vibration, EMI and chemical exposure. This makes it ideal for use in all military and aerospace environments.
STURDY MECHANICAL DESIGN
Atr 3 Slot Free Play
The E104 is constructed of durable CNC machined 6061-T6 aluminium. Fasteners are stainless steel and often-used threads have self-locking stainless steel helicoils to withstand severe vibration and shock. All connectors are
located on the front panel of the enclosure for easy access. Side and back walls are equipped with heat conducting mounting bars to the bottom side of the enclosure for cold-plate direct mounting. The E104 is also equipped with a built-in handle for carrying purposes.
BOARD CAPACITY
The E104 accommodates 5 standard VME boards with 0.8-inch pitch, including:
- IEEE 1101.2 conduction-cooled VME cards
- Commercial VME boards without front panels
VME BACKPLANE
Atr 3 Slot Speed
The backplane is VME64x compliant with 160- pin, 5-row J1/J2 connectors and 95-pin PO connectors in all slots. Any of the pins in rows A and C, and user-defined pins in rows Z and D of the J2 connectors, as well as the 95 I/O pins from each of the P0 connectors (up to a maximum of 512),
